Linux Operation System

ARM 9G20 400MHz CPU, embedded Linux OS to support faster data transmission.

Multi Constellation Tracking

l  220 tracking channels.

l  Supports GPS, GLONASS, GALILEO, BDS, SBAS.

l  Built-in NGS Approved Antenna.

High Power Transceiver UHF Radio

l  The transceiver UHF radio enables the working mode switchable between base and rover.

l  5 watts (Max.) HI-TARGET internal UHF radio and 2 watts (Max.)Pacific Crest micro XDL internal UHF radio are optional

l  Pacific Crest TrimTalk© internal UHF radio is compatible with other RTK.

PERFORMANCE SPECIFICATIONS

MEASUREMENTS

• 220 Channels

• Advanced Pacific Crest Maxwell 6 Custom Survey GNSS Technology

• High precision multiple correlator for GNSS pseudo range measurements

• Unfiltered, unsmoothed pseudo range measurements data for low noise, low multipath error, low time domain correlation and high dynamic response

• Very low noise GNSS carrier phase measurements with <1 mm precision in a 1 Hz bandwidth

• Signal-to-Noise ratios reported in dB-Hz

• Proven Pacific Crest low elevation tracking technology

Satellite signals tracked simultaneously

GPS              : Simultaneous L1C/A, L2C, L2E, L5

GLONASS      : Simultaneous L1C/A, L1P, L2C/A (GLONASS M only), L2P

SBAS            : Simultaneous L1 C/A, L5

Galileo           : Simultaneous L1 BOC, E5A, E5B, E5AltBOC

BDS/Compass: B1, B2

QZSS                     : L1 C/A, L1 SAIF, L2C, L5

POSITIONING PERFORMANCE

Static and Fast Static GNSS surveying

Horizontal      : 2.5mm+0.5ppm RMS

Vertical         : 5mm+0.5ppm RMS

Post Processing Kinematic

(PPK / Stop & Go) GNSS surveying

Horizontal                : 1cm+1ppm RMS

Vertical                   : 2.5cm+1ppm RMS

Initialization time       : typically 10 minutes for base while 5 minutes for rover

Initialization reliability: typically > 99.9%

Real time Kinematic (RTK) surveying

Horizontal                : 8mm+1ppm RMS

Vertical                   : 15mm+1ppm RMS

Initialization time       : typically < 8 seconds

Initialization reliability: typically > 99.9%

Code Differential GNSS positioning

Horizontal      : 25cm+1ppm RMS

Vertical         : 50cm+1ppm RMS

SBAS            : 0.50m Horizontal, 0.85m Vertical

HARDWARE

Physical

Dimensions (W x H): 18.20cm x 9.80cm (7.17 in x 3.86 in)

Weight                             : 1.25kg (2.76lb) without internal battery

Operating temperature        : -45℃ to +65℃ (-49℉ to +149℉)

Storage temperature          : -55℃ to +85℃ (-67℉ to +185℉)

Humidity                           : 100%, considering

Water/dustproof                : IP67 dustproof,  immersion to depth of 1m (3.28ft).

Shock and Vibration            : Designed to survive a 3m (9.84ft) natural fall onto concrete.

Electrical

Power 6V to 28V DC external power input

Power consumption ≤3.5W

Automatic Switching between internal power and external power

Rechargeable, removable 7.4V, 5000mAh Lithium-Ion battery in internal battery compartment

Internal battery life

Static 13 - 15 hours

RTK Rover (UHF/GPRS/3G) 10 - 12 hours

RTK Base 8 - 10 hours

I/O interface

1 x Bluetooth

1 x standard USB2.0 port

1 x TNC UHF connector

2 x RS232 serial port

2 x DC power input (8-pin & 5-pin)

1 x Micro SD card port

COMMUNICATION AND DATA STORAGE

3G Communication

Fully integrated, fully sealed internal 3G, compatible with GPRS

Network RTK (via CORS) range 20-50km

HI-TARGET internal UHF radio (standard)

Frequency               : 450~470MHz with 116 channels

Transmitting Power   : 1W, 2W, 5W adjustable

Transmitting Speed   : 9.6Kbps, 19.2Kbps

Working Range         : 5km typical, 8~10km optimal

Pacific Crest internal UHF radio

Frequency               : 403~473 MHz

Transmitting Power   : 0.5W, 2W adjustable

Transmitting Speed   : Up to 19.2Kbps

Support most of radio communication protocol

Working Range         : 3~5km typical, 8~10km optimal

 Contact : 081333102011 atau 021.7321129

HI-TARGET External UHF radio (standard)

Frequency               : 460 MHz with 116 channels

Transmitting Power   : 5W, 10W, 20W, 30W adjustable

Transmitting Speed   : Up to 19.2Kbps

Working Range         : 8~10km typical, 15~20km optimal

Pacific Crest ADL Vantage Pro External UHF radio

Frequency               : 390~430 MHz or 430~470 MHz

Transmitting Power   : 4W to 35W adjustable

Transmitting Speed   : Up to 19.2Kbps

Support most of radio communication protocol

Working Range         : 8~10km typical, 15~20km optimal

Support other external communication device

For example, external GSM modem.

Data storage

1GB Internal storage+ 8GB Internal Micro SD Card memory (Support up to 32GB extension)

Record GNS and Rinex format simultaneously

Data formats

(1Hz positioning output, up to 50 Hz - depends on installed option)

CMR: sCMRx, CMR, CMR+ input and output

RTCM: RTCM 2.1, 2.2, 2.3, 3.0, 3.1, 3.2 input and output

Navigation outputs ASCII: NMEA-0183 GSV, AVR, RMC, HDT, VGK, VHD, ROT, GGK, GGA, GSA, ZDA, VTG, GST, PJT, PJK, BPQ, GLL, GRS, GBS

Navigation outputs Binary: GSOF

1 Pulse Per Second Output
